KF04060BK Body Cab Mount Bushing Kit for Ford F250 F350 Super Duty 2/4WD 08-16

$88.88
Compare

visamasteramerican expressunionpayshopify payapple paygoogle pay
Vendor: Trending Home Tech
SKU:
Availability : In Stock Pre order Out of stock
Description

  • KF04060BK Body Mount Bushing Kit Fits for Ford F250 F350 Super Duty 2WD 4WD 2008-2016 Polyurethane Body Cab Mounts & Hardware & Steel Sleeves (Black)


  • [Application] Works well for Ford Super Duty 2008-2016 F-250 | 2008-2016 F-350. Precision-engineered to be a direct replacement for factory rubber mounts.

  • [Function] Used to attach a body and frame, and replace the vulnerable rubber body mounts which can become deformed with excessive wear and exposure to the elements. You can replace the hardware along with the bushings all with one kit and upgrade the longevity of your body to frame alignment.

  • [Material] Constructed from a special polyurethane blend , which is strength and no-deformation, Impact resistance and for years to use. Help to protect your body to frame attachment and your smooth ride. Also includes OE-style replacement steel sleeves and hardware.

  • [Benefits] Sunluway body mounts can resistance to vehicle fluids and road grime. They outlast factory body mounts and provide more positive attachment to the frame. Make it become more effective at isolating the cab from chassis noise and vibration, increasing performance and handling.

  • [SATISFACTION GUARANTEE] If you're not 100% satisfied with this Body Mount Bushing Kit, simply return it for a full refund in 30 days, guarantee with 12 months’ warranty.




KF04060BK Body Mount Bushing Kit Fits for Ford F250 F350 Super Duty 2WD 4WD 2008-2016

Fitment



  • Work well for Ford F-250 F-350 2WD and 4WD 2008-2016



Models



  • Super Duty XL, XLT, FX4, Lariat, Platinum, Cabela's, King Ranch, Harley-Davidson Edition.



Why you need this?



  • Once the rubber starts to fail, the attachment point is compromised and the bushing can literally just fall off. Without body to frame mount bushings, the smooth connection between your body and frame is gone and your smooth ride is gone with it. Now bumps and potholes will really put your seatbelt to work. Protect your soft ride and your body to frame alignment with Sunluway KF04060BK Body Mount Bushing Kit



1
1

Installation Guide:



  1. All POSITONS - Remove the bolts from the passenger side body mounts and loosen the driver’s side body mount bolts, but do not remove them.
  2. POSITION 1 - On the front radiator support bolts, you will need to remove the upper nut on the inside of the radiator support and then you can loosen the lower bolt. A 24” extension with a universal swivel and an 18mm socket works well for this on most trucks. You might need to have someone hold the mounts with large adjustable pliers while you loosen the bolts. On some models, the front bumper must be removed to access the bolts.
  3. Using a floor jack, carefully place the jack on the passenger side floorboard support mounts and lift high enough to remove the body mounts. Make sure the cab is securely supported with jack stands before working under the truck or removing anymounts.
  4. ALL POSITIONS - Remove and replace the passenger side body mounts one at a time. Take care not to mix up the pieces. The upper and lower mounts are clipped together on the frame and you may have to use a pair of large screwdrivers to pry the mounts off.
  5. ALL POSITIONS – Install kit body mounts on kit steel mounts, Assemble the kit components.
  6. ALL POSITIONS – When installing the new assemblies onto the frame, make sure they are seated into the frame and centered in the hole.
  7. POSITION 1 – Install kit body mount M04060-02 on the top, and kit body mount M04060-01 along with kit washer S10126 on the bottom. Run the bolt in from the bottom and start it but don’t tighten it yet. Start the upper nut on the radiator support but don’t tighten it yet.
  8. (POSITIONS 2, 3, & 4 – Working on one position at a time, install kit body mount M04060-02 on the large kit steel top half and kit body mount M04060-01 on the small kit steel bottom half. Start the bolts but do not tighten.)
  9. Repeat steps 1 through 10 for the driver’s side.
  10. Tighten all bolts in an alternating cross pattern (as with tightening wheel lug nuts) until you can feel the stock metal shells seat together (around 45-55 ft. lbs.). Tighten the top nut on the radiator core support mount last.
  11. Reinstall the body cab plugs, and if removed, reinstall the seat, trim, and upholstery.
  12. Reinstall the airbag fuse and reconnect the battery.
